I will create stm32 cm5 raspberry pi compute module and advanced pcb design services
About this Gig
WELCOME!
I specialize in STM32 based systems, Raspberry Pi Compute Modules, CM5 platforms, and advanced PCB design, from initial schematics through PCB layout and manufacturing ready files.
What I Can Design
- STM32 based embedded systems and custom development boards
- Raspberry Pi Compute Module and CM5 carrier boards
- High-speed digital circuit boards
- Custom processor and microcontroller boards
- Power management and power supply circuits
- Sensor and IoT boards
- Communication interfaces and peripheral circuits
- USB, Ethernet, UART, SPI, I²C, CAN, RS-485 and other interfaces
- Multi-layer PCB designs
- Compact and space constrained PCB layouts
- Prototype and production ready hardware
What You Will Receive
Depending on your project requirements, I can provide:
- Complete circuit schematics
- Professional PCB layout
- Component selection and footprints
- Design Rule Checking (DRC)
- Electrical Rule Checking (ERC)
- PCB manufacturing files (Gerbers)
- Drill files
Please message me before placing an order so I can review your project specifications and recommend the most suitable approach.
File format:
Gerber
•
STEP
•
SCH
•
3DS
•
Software:
Allegro
•
Altium Designer
•
Eagle CAD
•
EasyEDA
•
KiCad
•
Proteus
Interface:
HDMI
•
I2S
•
USB
•
SPI
•
PCIe
•
BLE
•
LTE
FAQ
What information do you need to start the project?
I need your project requirements, schematic or block diagram (if available), board dimensions, component requirements, interfaces, and any specific design constraints.
Can you design custom STM32 boards?
Yes. I can design custom STM32-based boards, including power management, communication interfaces, sensors, connectors, and other required peripherals.
Can you design Raspberry Pi CM5 carrier boards?
Yes. I can design custom carrier boards for Raspberry Pi Compute Modules, including CM5-based systems and required peripheral interfaces
Do you provide PCB manufacturing files?
Yes. Depending on the selected package, I can provide Gerber files, drill files, BOM, pick-and-place files, and other manufacturing documentation.
Can you design multi-layer and high-speed PCBs?
Yes. I can work on advanced multi-layer PCB designs involving high-speed interfaces, power management, and complex routing requirements.
Will you provide the source design files?
Yes. Source files can be included according to the selected package and project requirements.
Should I contact you before placing an order?
Yes. Please send your requirements before ordering so I can review the project scope and provide the appropriate package and pricing.
Can you help select components?
Yes. I can assist with component selection based on functionality, availability, specifications, cost, and PCB requirements.
