I will design custom pcb layouts and schematics in kicad
Flutter, Firebase, MATLAB and KiCad PCB Design
I'm Muhammad Waleed Khan, an Electrical Engineering undergraduate at UET Mardan. I have about three years of local web and app development experience through Waleed Electronics and Software House.
I ...
About this Gig
I work on custom PCB projects in KiCad from agreed requirements or an existing circuit. The scope can include schematic capture, component/footprint review, layout, revisions and manufacturing-file handover.
Board dimensions, components, layers, power, interfaces and mechanical constraints determine the quote. Larger boards are welcome for individual review; the dimensions of my portfolio sample are not a service-size limit.
You receive editable KiCad files and the agreed schematic export, BOM, Gerber/drill files, placement data, 3D views and check reports. My current demonstration is an unpaid digital design with configured ERC/DRC checks, not a manufactured or bench-tested product.
Please contact me with requirements before ordering. Fabrication, assembly, physical tests, RF/high-speed validation and compliance are separate, explicitly reviewed milestones.
Specialization:
Schematics
•
Layout
•
Gerber
File format:
Gerber
•
•
Other
Software:
KiCad
Interface:
Other
My Portfolio
FAQ
Do you design a circuit from just an idea?
The listed packages translate a defined circuit into a schematic or PCB. New circuit development needs its own feasibility review, component decisions, and separate scope.
What files will I receive?
Basic includes editable schematic files and a PDF. PCB packages include the KiCad project, Gerbers, drill files, a BOM, a 3D preview, and a brief ERC/DRC check summary.
Are fabrication, assembly, and hardware tests included?
No. These are digital design packages. You arrange manufacturing and assembly, and verify electrical performance through physical prototype testing.
Which types of PCB are covered?
Custom boards are reviewed against the package component, size and layer limits. Larger boards or extra layers need an individual quote. Power, RF, mains and high-speed work require feasibility review; physical testing and compliance are separately agreed milestones.
Can you use my chosen components and fabricator?
Yes, if you provide the datasheets, footprints or verified dimensions, board constraints, and fabrication rules. Please resolve unavailable or unsuitable parts before ordering.
What counts as a revision?
A revision corrects or adjusts the agreed schematic or layout. New components, changed circuit functions, a new outline, or added boards require separate scope.
