I will design ac dc rectifier bridge and power conversion circuits for electronics pcb
Power Electronics Design Engineer
I’m a Power Electronics Design Engineer specializing in practical, reliable circuit and hardware solutions. I design MOSFET & IGBT gate drivers, power switching circuits, AC-DC rectifiers, bridge rect...
About this Gig
Need a reliable AC-to-DC rectifier for your electronics or power conversion project?
An incorrectly designed rectifier can cause excessive ripple, overheating, voltage drops, poor efficiency, component failure and an unstable DC bus. Choosing the wrong diode, SCR, bridge configuration or component ratings can also create problems during testing and operation.
I will design a custom rectifier and AC-DC conversion stage based on your input voltage, output voltage, current, power and application requirements.
What I Can Help With
- Bridge rectifier circuits
- AC-DC conversion
- Diode rectifiers
- Three-phase rectifiers
- Controlled rectifiers
- SCR/thyristor rectifiers
- DC-link and filtering stages
- Voltage and current protection
Deliverables
Schematic, calculations, component selection, simulation where required, BOM, Gerber and source files according to your package.
File Formats
PDF, BOM, Gerber, KiCad, Altium, EasyEDA and supported source formats.
Software Used
KiCad, Altium Designer, EasyEDA and MATLAB/Simulink.
Why Choose Me
I design practical rectifier solutions around your actual electrical requirements, component ratings and application.
Kindly inbox me first before order.
FAQ
What type of rectifiers can you design?
I can design diode bridge, single-phase, three-phase, controlled and SCR/thyristor rectifiers.
Can you design a three-phase rectifier?
Yes, I can design three-phase rectification and DC-link stages based on your voltage and current requirements.
Can you include filtering?
Yes. Capacitor, inductor and other appropriate filtering stages can be included.
Can you work with high-voltage AC input?
Yes, the design can be developed according to the required voltage, current, power and component ratings.
Can you design the PCB too?
Yes, PCB design can be included depending on your selected package.
