I will convert scanned pcb, electronic components and hardware into cad files
About this Gig
HELLO AND WELCOME!!!
Turn scanned electronic components into accurate, production-ready CAD data.
A scanned component is more than a visual referenceit contains dimensional information that must be interpreted correctly for mechanical fit, enclosure integration, PCB clearance, and manufacturing. I will convert your 3D scans, scanned images, point-cloud references, or technical scan data into clean, editable CAD models suitable for engineering workflows.
What I Offer:
- Scan-to-CAD conversion of electronic components
- Accurate 3D CAD modeling and mechanical reconstruction
- STEP, STP, IGES, STL and other CAD formats
- PCB, connector, sensor, housing and enclosure modeling
- Dimensional reconstruction and feature matching
- Reverse engineering from scan/reference data
- Manufacturing-ready geometry and revisions
Why Choose Me?
I focus on engineering accuracy, clean topology, proper dimensions, and functional geometry rather than simply tracing a scan. Your model will be structured for practical use in product design, prototyping, enclosure development, PCB-mechanical integration, and manufacturing.
Have a scan ready? Send it over and let's convert your reference data into usable CAD geometry.
Other Electronics Engineering Services I Offer
FAQ
What types of scanned components can you convert into CAD?
I can convert scans of PCBs, connectors, sensors, housings, electronic components, brackets, and mechanical parts.
What scan files do you accept?
I can work with 3D scans, point clouds, mesh files, STL, OBJ, STEP references, images, and other available scan data
