I will do rf pcb design for GSM, gnss, lora, ble using sx1276, sim868, mc60

A tracker or IoT device that "works on the bench" but drops signal in the field almost always has an RF layout problem.

I design RF PCBs that get a clean signal from the antenna to the module and pass real-world testing.

I work with GSM/GPRS, GNSS/GPS, BLE and LoRa devices using SX1276, SIM868, MC60 and similar modules (LTE-M/NB-IoT options such as SIM7080G on request).

WHAT'S INCLUDED:

• Schematic review and RF-aware component selection
• 2 to 6 layer layout with 50-ohm controlled impedance
• Antenna matching (pi network), keep-outs and via stitching
• GSM, GNSS and BLE coexistence planning
• Power design for GSM burst current
• Antenna design and simulation in HFSS/CST (Premium)
• EMI/EMC-aware layout and DFM review

YOU RECEIVE:

Gerbers, BOM, pick-and-place, PDF schematic, STEP model, source files (Altium/KiCad/EasyEDA), RF layout notes and simulation reports where ordered.

Message me first with your module list, board size and target region so I can confirm scope before you order.
