I will do electronic design pcb design, layout robotics and schematic for manufacturing
About this Gig
Hello and Welcome!
Ever waited days for a PCB design only to find routing errors or a board your fab house rejects outright? A bad layout doesn't just waste money it wastes your production timeline.
I design manufacture-ready PCBs, schematic to Gerber, built to pass JLCPCB, PCBWay, or any fab house's checks the first time, not the third.
What you'll get:
- Schematic capture & PCB layout in Altium, KiCad, or EasyEDA
- Single, 2-layer, or multilayer boards, RF & impedance-controlled routing
- Gerber, BOM, Pick-and-Place & drill files, fab-house compatible
- DFM/DRC check before delivery, not after you've ordered boards
- ESP32, Arduino, STM32 & IoT layouts, power and signal integrity done right
Why buyers choose me:
No message me first gatekeeping tell me your project in the order form and I start immediately. I explain every routing decision in plain English, and revisions stay open until your board is genuinely ready to fabricate.
A quick schematic redraw or a full multilayer production board I scope it upfront, no scramble over unclear requirements halfway through.
Send your schematic, sketch, or datasheet and I'll tell you exactly what it takes, free, before you commit.
Specialization:
Circuit design
•
Schematics
•
Layout
•
Gerber
File format:
Gerber
•
VRML
•
BRD
•
ODB
Software:
Altium Designer
•
EasyEDA
•
KiCad
•
LTspice
•
Proteus
•
Arduino
FAQ
What happens if my manufacturer flags an issue after I place a fabrication order?
I'll review the flag and correct the file within your revision window at no extra cost the goal is a board that fabricates cleanly, not just a file marked "delivered."
Can you also write the firmware for the board?
Yes, on the Premium package ESP32, Arduino, and STM32 firmware can be bundled so you're not coordinating two separate freelancers for one product.
Do you provide the source project files, not just Gerbers?
Yes every tier includes source files (Altium/KiCad/EasyEDA project) so you own the design outright and can hand it to any other engineer or manufacturer in the future.
What if I don't know how many layers I need?
That's normal most buyers don't. Tell me your project's function, size constraints, and rough budget, and I'll recommend the right layer count and stack-up before we start.
Will my Gerber files actually pass JLCPCB or PCBWay's checks?
Every package includes a DFM/DRC review before delivery specifically to catch issues fab houses reject clearances, hole sizes, copper-to-edge distances, and layer stack-up problems.
