I will rf pcb and compute module carrier boards, manufacturing ready pcb design
3D Character Product Animator Photorealistic Rendering Assets3D Character
I am a professional 3D artist specializing in high-end character creation, product modeling, and photorealistic animation. I bring concepts to life through meticulous geometry, clean topology, detaile...
About this Gig
Specialized PCB design covering everything from standard schematic and layout work to advanced RF circuits and compute module carrier boards the kind of projects most generalist PCB designers turn away.
RF PCB design includes proper impedance-controlled traces, ground plane management, and antenna placement for wireless modules (LoRa, GPS, BLE, Wi-Fi), so signal integrity issues don't show up after fabrication. Compute module carrier boards for Raspberry Pi CM4/CM5 are built around correct pinout mapping, power sequencing, and connector placement, tested against manufacturer reference designs before delivery.
Every design whether a simple 2-layer board or a complex multilayer RF layout is checked for manufacturing readiness (DFM) before files are handed over, meaning fewer fabrication errors, fewer respins, and a smoother path from design to production at JLCPCB, PCBWay, or any other fab house.
Files are delivered in KiCad, Altium, or EasyEDA depending on preference, complete with Gerbers, BOM, and pick-and-place files ready for assembly.
My Portfolio
FAQ
Do you handle RF-specific concerns like impedance matching and antenna placement?
Yes — RF PCB work includes controlled impedance traces, proper ground plane design, and antenna placement/keep-out zones for common wireless modules, so the board performs correctly on first fabrication.
Can you design a carrier board specifically for the Raspberry Pi Compute Module (CM4/CM5)?
Yes — carrier boards are designed around the CM4/CM5's official pinout and power requirements, with correct connector placement and signal routing validated against the reference schematic.
Will the design be manufacturing-ready, or do I need to fix things before sending it to a fab house?
All designs go through a manufacturing-readiness check (DFM) before delivery — trace widths, clearances, and layer stack-up are verified against standard fab house tolerances (JLCPCB, PCBWay) to avoid rejected orders.
