I will do high quality pcb design and schematic layout for your project
Electronics Engineer, PCB Designer, Hardware Developer
Electronics Engineer | Senior PCB Designer | Hardware Developer
With over nine years of experience in Electronics Engineering, I fuse profound passion with professional excellence. Specializing in co...
About this Gig
Are you looking for a professional, manufacturing-ready PCB design for your next electronic product? You are in the right place!
I am a professional PCB Design & Electronics Engineer with extensive industry experience in turning circuit concepts into high-quality, reliable, and production-ready Printed Circuit Boards. Whether its a simple breakout board or a complex multi-layer high-speed system, Ive got you covered.
What I Can Design For You:
- Multi-layer PCBs: Single, Double, and Multi-layer designs (up to 12+ layers) with optimized routing.
- Power Electronics: SMPS, LED Drivers, Battery Chargers, and High-Power circuits.
- Embedded Systems & IoT: ESP32, Arduino, and ARM microcontroller-based hardware.
- High-Speed Designs: Controlled impedance routing, signal integrity, and proper decoupling.
️ Software Expertise:
- Altium Designer
- KiCad
- EasyEDA
What Deliverables Will You Get?
- Gerber Files (RS-274X format for manufacturing)
- NC Drill Files
- Bill of Materials (BOM) with component sourcing links (DigiKey, Mouser, LCSC)
- Schematic & PCB Layout files (Source files)
- 3D STEP File of the PCB for enclosure fitment testing
- Pick and Place / Centroid File (for SMT assembly)
File format:
Gerber
•
SCH
•
•
ODB
Software:
Altium Designer
•
EasyEDA
•
KiCad
•
CircuitMaker
Interface:
USB
•
I2C
FAQ
Q: What do you need to start the design?
A: I need the schematic diagram (if you have one), a clear project description, the required PCB dimensions/shape, and any specific component preferences or constraints.
Q: What if I don't have a schematic diagram?
A: No problem! Just share your detailed concept, project requirements, or a block diagram. I can create the schematic from scratch for an additional fee before moving to the PCB layout.
Q: Will my PCB design be ready for manufacturing?
A: Yes, absolutely. All my designs strictly follow DFM (Design for Manufacturing) standards, and I provide standard Gerber and Drill files that are accepted by all major PCB manufacturers globally.
Q: Do you provide 3D models of the board?
A: Yes, I provide a 3D STEP file of the completed board in the Standard and Premium packages, which helps you design enclosures or casings perfectly.
