I will provide grid interconnection study medium voltage sld, high voltage cad drafting

Looking for professional grid interconnection study schematics, medium voltage SLD, and high voltage CAD drafting compliant with IEEE, IEC, NERC, and NEC standards? I deliver code compliant electrical CAD packages for utility scale solar, BESS, and high voltage transmission grid tie projects.

Core Technical Engineering Deliverables:

• Grid interconnection study schematics and point of interconnection (POI) CAD sets
• Medium voltage single line diagrams (MV SLD) up to 34.5kV utility distribution
• High voltage CAD drafting (69kV115kV+) for transmission substation tie-in
• Three line diagrams, protection relay schemes, and CT/PT metering layouts
• Transformer specs, switchgear ratings, breaker sizing, and interlock plans
• Short circuit & load flow schematics for AHJ and utility permit submittal
• Native AutoCAD DWG engineering source files, vector PDFs, and detailed BOM

From utility application submittal to final interconnect approval, every drawing set is engineered for rapid utility clearance and EPC execution.

Provide your project single line sketch, POI specs, and grid voltage to get started!
