I will design pcb layouts circuit schematics hardware and altium design
PCB Design , Electronics Engineering , Altium, ESP32, Arduino and STM32
I’m a professional PCB designer and electronics engineer specializing in PCB layout, circuit schematics, and hardware prototyping. I design reliable and production ready boards using Altium Designer, ...
About this Gig
Looking for a professional PCB designer to turn your electronics idea into a reliable, production ready board? I can help!
I specialize in PCB layout, circuit schematic, and hardware development using Altium Designer. Whether you have an existing schematic, a concept, or need a PCB designed from scratch, I will create a clean, functional, and well-organized design.
What I Offer:
- Custom PCB layout
- Professional circuit schematics
- Component selection and footprint assignment
- PCB routing and optimization
- Design for manufacturability (DFM)
- Hardware prototyping support
- Design review and troubleshooting
What You will Receive:
- Altium project/source files
- PCB layout and schematic files
- Gerber and drill files
- BOM (Bill of Materials)
- Manufacturing-ready documentation
Software I Use:
- Altium Designer, LTspice, KiCad, EasyEDA
Why Choose Me?
- Professional and detail-oriented
- Clean, organized PCB
- Reliable communication
- Focus on quality and manufacturability
Have a project in mind? Send me your requirements today and let's turn your idea into a professional PCB!
FAQ
What PCB services do you provide?
I provide professional PCB layout, circuit schematic, and hardware development services using Altium Designer. I can help with single layer, 2 layer, and multilayer boards, component placement, routing, libraries, and production-ready files.
Can you design both the circuit schematic and PCB layout?
Yes. I can create or modify circuit schematics and develop the corresponding PCB layout, including component placement, routing, power and ground planes, and design rule checks.
Can you work with an existing PCB or schematic?
Yes. I can modify, optimize, troubleshoot, or redesign existing PCB layouts and schematics. You can provide your Altium project files, schematics, Gerbers, or other available technical documentation.
What files will I receive after the project?
Depending on your package, deliverables can include Altium source files, PCB layout, schematic, BOM, Gerber files, drill files, and other fabrication ready documentation required for manufacturing.
What do you need from me to start?
Please provide your schematic, circuit requirements, component list, board dimensions, preferred components, and any manufacturing constraints you have. If you only have an idea or basic requirements, contact me first so I can recommend the best approach
