I will do a custom gameboy ips screen mod and usb c charging pcb

Are you designing custom upgrade kits or replacement electronics for classic Nintendo handhelds?

I specialize in engineering compact, high-efficiency PCB drop-in replacement mods specifically tailored for the Game Boy product line. From modernizing power management with protected USB-C lithium charging to designing low-noise power regulation for modern bright IPS screen kits, I design boards that seamlessly drop into original retro handheld plastic shells.

What I design for:

• Game Boy Original (DMG-01) & Game Boy Pocket (MGB-01)
• Game Boy Color (CGB-01)
• Game Boy Advance (AGB-001) & Advance SP (AGS-001)

Design focal points I ensure for your kit:

• Power Safety: Integrated overcharge/overdischarge protection for Li-po batteries via USB-C.
• Perfect Shell Fitment: Accurate alignment of screw holes, battery contacts, and cartridge slots.
• Audio Filtering: Separated grounding and shielding traces to eliminate standard background hums.

What you will receive in your delivery package:

• Production Gerber Files completely ready to upload to JLCPCB, PCBWay, etc.
• Optimized BOM featuring common components easily sourced from LCSC or DigiKey.
• CPL Assembly Files for seamless machine pick-and-place sourci
