I will design vtol uav or fixed wing drone cad model for 3d printing
Samuel O
About this gig
You've mapped out your VTOL or fixed-wing UAV payload specs, mission profile, motor layout.
But turning that into a flight-ready 3D printable CAD design is where most builds stall.
Generic drone frames don't work. A VTOL UAV needs precise tilt-rotor geometry, correct CG placement, and clean transition mechanics.
A fixed-wing needs proper airfoil-informed fuselage profiling and servo bay clearances. Get it wrong and you're reprinting everything.
That's what I prevent.
I design custom VTOL UAVs, fixed-wing drones, and hybrid aircraft specifically for 3D printing built around your payload, propulsion system, and mission requirements.
Whether it's an agricultural sprayer UAV, a long-range mapping drone, or a VTOL delivery platform, you get a design that flies.
Every file is FDM-optimized: correct wall thicknesses, minimal supports, structural ribs where they matter, and proper hardware insert tolerances.
Deliverables include print-ready STL files, STEP files (Standard & Premium), and full technical notes on assembly and print settings.
Send me your specs and let's get your UAV designed right.
Delivery style preference
Please inform the freelancer of any preferences or concerns regarding the use of AI tools in the completion and/or delivery of your order.
Get to know Samuel O
Samuel O
UAV, drone and RC aircraft CAD designer
- FromUnited Kingdom
- Member sinceApr 2026
- Avg. response time3 hours
Languages
English, Spanish, German
Got a drone idea but no CAD file to build it? That's where I come in.
I specialize in custom UAV, FPV drone, RC airplane, and VTOL aircraft CAD design, delivering clean, print-ready STL files optimized for 3D printing from day one.
Every design is built around your exact specs: motor size, frame dimensions, electronics layout, and intended use. No guesswork, no generic templates.
Whether you're a hobbyist building your first FPV quad, a startup prototyping an agricultural UAV, or an engineer needing a precise airframe, I deliver files that print right, first time.
FAQ
What types of VTOL and fixed-wing UAV designs can you handle?
I design the full range: tilt-rotor VTOL UAVs, hybrid fixed-wing VTOL platforms, conventional fixed-wing RC and UAV airframes, flying wings, delta wings, agricultural spray drones, mapping drones, and long-range delivery UAV designs. If it has a fixed lifting surface or transitions between hover and
Can you design a UAV that carries a specific payload or sensor?
Yes. Provide the dimensions and weight of your payload — camera, sensor array, spray tank, LiDAR unit — and I'll design the airframe with a dedicated payload bay, correct CG placement, and appropriate structural reinforcement around the mount area.
Do you provide aerodynamic analysis or just the CAD model?
The Standard and Premium packages include aerodynamic notes covering wing loading estimates, CG position, prop-wash considerations, and recommended print material for the mission profile. Full CFD analysis is available as a Premium add-on — message me to discuss.
Will your VTOL UAV design work with ArduPilot or PX4 flight controllers?
Yes — all fixed-wing and VTOL UAV designs include correct FC mounting geometry, vibration isolation boss placement, and GPS mast clearance compatible with ArduPlane, ArduCopter VTOL, or PX4 VTOL firmware configurations.
What information do you need to start my fixed-wing or VTOL UAV CAD design?
Wingspan or frame size target (mm), motor count and size, battery dimensions, payload description, mission type (mapping, agriculture, delivery, FPV, other), and any reference designs or inspiration images. The more detail you provide, the closer the first draft lands.
Can you design for carbon fiber manufacture as well as 3D printing?
Yes. The Premium package can include geometry optimized for hybrid manufacture — 3D printed formers and bulkheads with carbon fiber rod/tube integration points, which is the standard construction method for serious fixed-wing UAV builds.
