I will do heavy copper high current multilayer pcb for inverter, bms, solar, ups, smps
PCB Design Engineer RF, Power Electronics and Embedded Systems
I’m Theo Johnson, a PCB designer with over 9 years of experience helping clients turn complex electronics ideas into reliable, production-ready designs. If you’re struggling with signal integrity, RF ...
About this Gig
Gig Description:
Are you dealing with a high-power PCB where high current, heat buildup, voltage clearance, or power distribution is becoming a challenge? Inverter, BMS, solar, UPS, and SMPS boards need careful routing, copper, thermal, and multilayer design. I can help turn your schematic or concept into a clean, reliable, manufacturable PCB built around your requirements.
What I Offer
- Heavy copper PCB design(4oz, 6oz, 10oz and above)
- High-current PCB layout
- Multilayer PCB des!gn
- Inverter PCB des!gn(pure sine wave)
- BMS PCB des!gn(4S20S, high current)
- Solar PCB des!gn
- UPS PCB des!gn
- SMPS PCB des!gn
- High-current power routing
- Thermal-aware layout
What You Will Get:
- Clean and professional PCB layout
- Optimized power & ground planes
- Proper thermal management
- Complete manufacturing-ready files (Gerber, drill, BOM, Pick & Place)
- Clear documentation
Why Work With Me:
- Specialized in power electronics & high current designs
- Detail-focused and reliable layouts
- Clear and fast communication
- Designs ready for JLCPCB, PCBWay, and other manufacturers
Just send me your schematic, requirements, or even a rough idea and I will take care of the rest.
Message me now to get started!
FAQ
What do I need to provide to start?
Please send your schematic, component list (BOM), board size, copper thickness needed, and any special requirements.
Do you design heavy copper PCBs (4oz, 6oz, 10oz)?
Yes, I specialize in heavy copper and high current multilayer PCBs for power applications.
Will I receive manufacturing-ready files?
Yes. You will get Gerber, drill files, BOM, Pick & Place, and PDF documentation ready for JLCPCB, PCBWay, etc.
Can you design for inverter, BMS, solar and UPS boards?
Yes, I have strong experience designing PCBs for pure sine wave inverters, BMS, solar inverters, UPS and SMPS.
