I will do pcb design, schematic, multilayer pcb layout, electronics and iot hardware
Hardware Engineer, Advanced PCB Design And Embedded Systems Specialist
Welcome! I am an Electronics & Hardware Engineer specializing in advanced multi-layer PCB design, schematic capture, and embedded systems.
Whether you need high-speed layouts optimized for low-EMI, ...
About this Gig
Need a production-ready, high-speed PCB layout that functions flawlessly? You are in safe hands.
I am a professional hardware engineer specializing in high-performance multi-layer PCB design. I optimize every single layout for signal integrity, proper power distribution networks (PDN), and low electromagnetic interference (EMI).
What I deliver:
- - Flawless Schematic Capture & verified connection mapping
- - Multi-layer PCB Layout (Altium, KiCad, or EasyEDA)
- - Production Files: Gerber (RS-274X/X2), NC Drill, Pick & Place
- - Clean Bill of Materials (BOM) with active component supplier links
- - 3D STEP models for perfect mechanical enclosure fit
I design strictly to industry IPC/IEEE standards, ensuring your manufacturer (like JLCPCB or PCBWay) can fabricate your board immediately without errors or delays.
Let's bring your hardware concept to life safely and professionally. Contact me today to discuss your project requirements!
FAQ
What software tools do you use for PCB design?
I work natively in industry-leading EDA software including Altium Designer, KiCad, and EasyEDA. I can deliver the exact source files compatible with your preferred design platform.
Can you design a PCB if I only have a basic hand-drawn schematic or an idea?
Yes, absolutely! I can take your block diagrams, component lists, or conceptual sketches, turn them into a professional schematic diagram first, and then build the full layout.
What files do I need to send to the manufacturing factory?
I provide a complete fabrication package. This includes standard Gerber files, NC Drill files, a Bill of Materials (BOM) for component sourcing, and Pick & Place files for assembly lines.
Do you sign Non-Disclosure Agreements (NDAs) to protect my intellectual property?
Yes. I treat your intellectual property with absolute confidentiality. I am fully open to signing an NDA before you share any sensitive project schematics, ideas, or files.
What happens if the manufacturer finds an issue with the delivered files?
Your engineering success is my priority. In the rare event that a fabrication house flags a layout variance, I will modify and update your files immediately free of charge.
